Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute

  • Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute
  • Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute
  • Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute
  • Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute
  • Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute
  • Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute
Luogo di origine Guangdong, Cina
Marca Goldantell/OEM
Numero di modello Serie GAT-218
Quantità di ordine minimo 2
Prezzo $611

Contattami per campioni gratuiti e coupon.

CosaAPP:0086 18588475571

WeChat: 0086 18588475571

Skype: sales10@aixton.com

In caso di dubbi, offriamo assistenza online 24 ore su 24.

x
Dettagli
Umidità ≤ 95% senza condensazione Intervallo di temperatura -15°C-75°C
Velocità di transito 30-40 persone al minuto Tensione di potenza AC220 (10%più o meno) V, 50HZ
Interfaccia porta standard-RS485 Lunghezza del braccio 285 mm
Materiale quadro un acciaio inossidabile di 304 gradi Grado di protezione IP54
Dimensione L1200*P280*H1000 (mm) Lunghezza del lembo 285 mm
Spessore del lembo 18 mm Peso netto 150 kg/paio
Larghezza standard del passaggio 550 mm Tensione del motore DC24V
Distanza di comunicazione meno di 1200 metri
Evidenziare

304 Grade Stainless Steel Flap Turnstile

,

IP54 Protection Flap Turnstile

,

30-40 Persons per Minute Flap Turnstile
Lasciate un messaggio
Descrizione di prodotto
Intelligent Enter and Exit Access Control Gate Electronic Barrier Smart Card Door Flap Turnstile with RFID Interface
Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute 0 Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute 1
Technology Specifications
Material 304 stainless steel (standard) or Painted Steel
Flap Wing Acrylic glass (standard), Resin, or PVC
Dimensions L1200 × W280 × H1000 (mm)
Optical Turnstile Flap 285mm (length), 18mm (thickness)
Net Weight 150Kg/pair
Standard Passage Width 550mm
Power Supply 220V, 240V, or 110V 50Hz/60Hz
Motor DC24V
Communication Interface RS485 (distance less than 1200 meters)
Input Interface Dry contact signal or 12V level signal or DC12V pulse signal
Driving Current > 10mA
Normal Lifespan 3 million cycles
Transit Speed 30-40 persons/minute
Open/Close Time 1 second
Working Environment Indoor/Outdoor (with cover), Temperature: -15°C to 75°C, Humidity: ≤95% (no condensation)
Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute 2 Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute 3
Key Features and Functions
  • Self-diagnostic problem detection system
  • Multiple operation modes including bi-directional card reading and single-direction photocell control
  • Automatic arm opening during power failure with auto-hold when power returns
  • Adjustable closing delay (1-60 seconds)
  • Auto-reposition function with configurable timeout period
  • Anti-tailgating alarm system
  • RS485 interface for remote control
  • Anti-rush mechanism with tight hold when no open signal
  • Dual anti-pinch protection: photocell and mechanical
  • Standard electrical interfaces for various reader integration
  • Passenger counting with LED display
  • Directional guidance indicators
  • Memory and non-memory card reading options
  • Population control through management software
  • Quiet operation with stable performance
Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute 4 Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute 5
About Shenzhen Goldantell Technologies Co., Ltd

We are a leading exporter and supply chain service provider of intelligent turnstile and parking management products with over 8 years of experience.

Our product range includes intelligent turnstiles, parking barriers, RFID cards, sentry boxes, wheel clamps, and related security access control systems. We have exported to more than 50 countries worldwide.

Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute 6 Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute 7
Our Services
  • Pre-sale consultation and product information
  • Production updates with photos and testing videos
  • Comprehensive after-sale support including installation guides
  • OEM/ODM services for custom branding and specifications
  • 16-hour professional support with prompt responses
Global Reach

We have successfully delivered turnstiles to over 50 countries including USA, Canada, Australia, European nations, Middle East, Africa, and Southeast Asia.

Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute 8 Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute 9
Trade Terms
  • 30-day valid quotation
  • 7-day delivery after payment confirmation
  • Payment methods: T/T, LC, Western Union, Escrow, PayPal
  • Packaging: Carton box with wooden case/crate
Delivery Options
  • Sea freight: 15-60 days (depending on destination)
  • Express shipping (UPS/DHL/FEDEX/TNT): 3-5 days door-to-door
  • Air cargo: 2-7 days
Contact Information
Intelligent Flap Turnstile with RFID Interface 304 Grade Stainless Steel IP54 Protection for 30-40 Persons per Minute 10

Goldantell turnstiles - factory direct pricing, premium quality, ready for your inquiry!
